Epoxy Resin Bushing

High Voltage Epoxy Resin Bushing for Power Transformer Insulation Systems

INQUIRY

At present, the APG process is adopted for manufacturing thermosetting epoxy resin both domestically and internationally. APG is an abbreviated process originating from Germany, short for Automatic Pressure Gelation, also known as the epoxy resin automatic pressure gel forming process.

The first step of the APG process is vacuum degassing. All raw materials are blended evenly in a vacuum tank with a stirrer, while a vacuum pump evacuates air continuously during mixing. Another function of stirring is to bring entrapped air inside the liquid mixture to the surface for vacuum removal. The vacuum level reaches -1, and the entire vacuum mixing cycle lasts approximately 90 minutes.

Epoxy resin is not poured under vacuum. The mixture is fully processed via vacuum mixing to eliminate all trapped air bubbles. During production, compressed air is introduced into the sealed vacuum tank. Driven by air pressure, the epoxy mixture flows through pipelines into the mold cavity to completely fill the mold, followed by a curing holding period until full solidification.

Epoxy Resin Bushing is a high-performance electrical insulation component widely used in power transmission and distribution systems. It is designed to provide reliable insulation and mechanical support for conductors passing through grounded barriers such as transformer tanks or switchgear panels. Manufactured with high-quality epoxy resin, it ensures stable performance under high voltage conditions..

Features

Made of high-strength epoxy resin material
Excellent electrical insulation performance
High mechanical strength and impact resistance
Good thermal stability and aging resistance
Suitable for indoor and outdoor applications
Smooth surface for easy installation and maintenance

Advantages

Long service life with low maintenance requirements
Reliable performance under high voltage environments
Resistant to moisture, dust, and chemical corrosion
Compact and lightweight design for easy handling
Cost-effective solution for power insulation systems

Application Scenarios

Power transformers
High and medium voltage switchgear
Substations and power distribution systems
Electrical control equipment
Industrial power transmission systems
Renewable energy power facilities (wind, solar substations)

Item	Value
Voltage	1kv
Current	1000-1600A
Type	Epoxy resin bushing
