600W N-Type TOPCon Mono Half-Cell Solar Panel 23.22% Efficiency (XD-M600)

600W N-Type TOPCon Mono Half-Cell Solar Module (XD-M600)

Product Overview
This 600W module adopts N-Type TOPCon cell technology (Longi cells) with a 144 half-cell layout (72 full cells cut in half, 6 columns × 24 rows) and a module efficiency of 23.22% — roughly 1.5 percentage points above conventional PERC, generating more energy from the same roof area. The large-format 2279×1134×30mm panel weighs 31.2kg and, combined with the anti-microcrack process and a 30-year product warranty, is the flagship choice for C&I rooftops and ground-mounted plants.

Key Features

• Leading N-Type TOPCon technology: 23.22% efficiency, better temperature behavior, excellent low-irradiance performance — smaller losses on cloudy days;
• 144 half-cell design: 6×24 half-cell layout reduces current loss and hot-spot risk, with a strong anti-cracking advantage;
• Electrical parameters (STC): Max power 600W; Vmp/Imp 43.3V/13.86A; Voc/Isc 51.41V/14.65A;
• 30-year product warranty: manufacturer-backed — better lifetime energy yield security;
• IP68 junction box + MC4 compatible connectors: long-term waterproof and dustproof, fast on-site wiring;
• Project friendly: 8 modules per string design recommendation; carton box with wooden pallet export packing.

Main Specifications (STC)

How It Compares with the 500-590W PERC Series

Typical Applications

Why Choose XD?
With years of manufacturing and export experience in new energy and power equipment, XD serves PV markets across Africa, Southeast Asia, the Middle East and South America. Solar panels, inverters, batteries and mounting structures are available as a package, with system configuration design and full export documentation support. Send us your roof area and load profile — our engineers will provide module selection and a full-container quotation.
