2.56kWh Flat Wall-Mount LiFePO4 Battery 25.6V 100Ah (Slim Home Storage)

2.56kWh Flat Wall-Mount LiFePO4 Battery · 25.6V 100Ah

Product Overview
This 25.6V 100Ah (2.56kWh) flat wall-mount LiFePO4 battery comes in a slim white housing with a built-in LCD display — hung on the wall with zero floor space. The built-in BMS provides over-voltage, under-voltage, over-current, over-temperature and short-circuit protection; multiple units can be paralleled (pack voltage difference <0.5V) or connected in series for higher voltage. Fanless natural cooling means silent, maintenance-free operation — an entry-level storage unit for residential PV storage and backup, scalable into larger systems.

Key Features

• LiFePO4 cells: inherently safe chemistry with long cycle life — lighter and more durable than lead-acid;
• Slim flat design: 415×368×192.9mm and only approx. 25.2kg — mount it in living rooms, balconies or utility rooms;
• LCD display: built-in screen shows capacity and operating status at a glance;
• Flexible expansion: parallel (pack ΔV<0.5V) and series connection supported — combine capacity as needed;
• 70A current: max. 70A charge and discharge handles typical household loads and inverter demand;
• Multi-level protection: over-voltage, under-voltage, over-current, over-temperature and short-circuit protection; M8 copper stud terminals for firm wiring;
• Maintenance-free: fanless natural cooling, silent operation; usable below 4000m altitude;
• Wide temperature range: charge 0~50℃, discharge -10~60℃ (recommended 15~40℃), storage -20~45℃.

Technical Parameters

Typical Applications

Why Choose XD?
With years of export experience in new energy and power equipment, XD offers a one-stop solar-storage-charging line — solar modules, hybrid inverters, storage batteries, EV chargers and cabling — with complete system configuration for your project. Capacity ratings, housing color, communication options and branding are customizable (OEM/ODM), with full export documentation support (please confirm UN38.3 / air-sea transport compliance for battery shipments in advance). Inquiries are welcome.
