5.12kWh Floor-Standing LiFePO4 Battery 25.6V 200Ah (LCD Display · WiFi Monitoring)

5.12kWh Floor-Standing LiFePO4 Battery · 25.6V 200Ah

Product Overview
This 25.6V 200Ah (5.12kWh) floor-standing LiFePO4 battery delivers 5120W rated power. The cabinet features an LCD screen plus SOC indicator lights and LED status lights, with WiFi remote monitoring; the built-in BMS provides over-charge, over-discharge, over-current, over-temperature and short-circuit protection. RS485/CAN/RS232 communication supports Pylontech, Growatt, Voltronic, MUST, GoodWe and other mainstream inverter protocols (customizable). Up to 16 units can be paralleled (80kWh+), making it ideal for home storage, shop backup and small off-grid plants.

Key Features

• LiFePO4 cells: inherently safe chemistry; 3000-cycle service life at 25℃ ambient — low cost per kWh over years of use;
• Rich display: LCD screen shows voltage/current/status, SOC indicator lights and LED status at a glance, with WiFi remote data access;
• Full communication, inverter-friendly: RS485, CAN and RS232, pre-loaded with Pylontech, Growatt, Voltronic, MUST, GoodWe protocols — custom protocols on request;
• High current capability: 40A standard charge/discharge, up to 100A continuous charge and 150A continuous discharge for heavy loads;
• 16-unit parallel expansion: up to 16 units in parallel (approx. 82kWh) — from home backup to small commercial storage in one step;
• Rugged cabinet: 1.2mm cold-rolled steel shell on swivel casters — easy to position and move;
• Complete protection: BMS charge cut-off 29.2V (cell 3.65V), discharge cut-off 20V (cell 2.5V), with over-charge/discharge/current/temperature and short-circuit protection;
• Wide temperature range: charge 0~45℃, discharge -15~55℃, storage -5~35℃ — fits varied installation environments.

Technical Parameters

Typical Applications

Why Choose XD?
With years of export experience in new energy and power equipment, XD offers a one-stop solar-storage-charging line — solar modules, hybrid inverters, storage batteries, EV chargers and cabling — with complete system configuration for your project. Capacity ratings, communication protocols, housing and branding are customizable (OEM/ODM), with full export documentation support (please confirm UN38.3 / air-sea transport compliance for battery shipments in advance). Inquiries are welcome.
